NORTON DOOR CONTROLS Grade 1 Heavy Duty Door Closer, Aluminum Finish
Regular price $446.83Heavy Duty Aluminum Door Closer
The NORTON DOOR CONTROLS Door Closer offers robust and reliable door control with its heavy-duty, grade 1 performance. This top frame-mounted closer provides smooth and effective operation for both interior and exterior doors, ensuring high-quality and long-lasting functionality.
Key Features:
- Grade 1 Heavy Duty: Built to endure high traffic environments with 25 million cycles.
- Versatile Mounting: Top frame mounting for doors with limited installation space on the door itself.
- Hydraulic Operation: Delivers controlled, smooth closing action ideal for a variety of settings.
- Durable Construction: Finished in sleek aluminum for a modern, weather-resistant look.
- Hold Open Functionality: Keeps doors open safely with adjustable spring tension control.
Specifications Table:
| Specification | Details |
|---|---|
| Manufacturer Part Number | UNI8301H x 689 |
| Brand | NORTON DOOR CONTROLS |
| Closer Mounting Type | Top Frame |
| Closer Series | Norton 8301 |
| Closer Stop Type | Spring |
| Closer Type | Hold Open |
| Color | Gray |
| Compatible with Brand | NORTON RIXSON |
| Display Qty | 1 |
| Display Sell UOM | EA |
| Max Door Opening Angle | 110 ° |
| Finish | Aluminum |
| Fire Rating | 3 hr |
| Housing Depth | 2-1/8 in |
| Housing Height | 2-7/8 in |
| Energy Source | Hydraulic |
| Includes | Plastic Cover |
| Includes Hardware | Hardware Not Included |
| Door Width Campatibility | 48 in |
| Location Use | Interior/Exterior |
| Standards | UL and cUL Listed |
| Spring Type | Adjustable |
| Height Between Mounting Holes | 3/4 in |
| Spring Size - Minimum | 1 |
| Material | Plastic |
| Exterior Door Width - Maximum | 48 in |
| Product Type | Door Closer |
| Spring Size | 6 |
| Arm Type | Parallel |
| Closer Cycles | 25,000,000 |
| Hand Orientation | Non-Handed |
| Housing Length | 13 in |
| Operation Style | Manual |
| Performance Duty Rating | 1 |
| Length Between Mounting Holes | 12 in |
| Ligature Resistance | Not Ligature-Resistant |
| ADA Compliant | Yes |
| Performance Rating | Grade 1 - Heavy Duty |
| Finish C | Aluminum Painted ; Plastic ; Gray |
Frequently Asked Questions (FAQ):
Q: Is this door closer suitable for exterior doors?
A: Yes, the NORTON DOOR CONTROLS Door Closer is designed for both interior and exterior use, making it versatile for various applications.
Q: How wide can the door be for this door closer?
A: This model is compatible with doors up to 48 inches wide.
Q: Does it comply with ADA standards?
A: Yes, this door closer is ADA compliant, accommodating all accessibility requirements.
Q: Is all necessary hardware included for installation?
A: Hardware is not included. Ensure all installation components are purchased separately.
Q: Can this door closer be used on fire-rated doors?
A: Yes, it is UL and cUL listed for a 3-hour fire rating, making it suitable for fire-rated door installations.
