Saturn IV Professional Gear Drive

This medium-area Pop-Up Gear-Drive Sprinkler Head covers areas from a 15 ft. up to a 30 ft. radius in a part- to full-circle spray pattern. The gear drive rotor ensures even and complete water coverage as well as a quiet spray. A filter protects the nozzle from clogging and is easily accessible for cleaning. It is compatible with all major brands of gear drive rotors including Rain Bird, Hunter, and Toro.

Features

Item Weight	0.35
Nozzle Material	Plastic
Minimum Spray Distance (ft.)	35
Pressure Rating	132
Irrigation System Component	Sprinkler
Color Family	Blacks
Sprinkler Angle Minimum (Degrees)	5
Sprinkler Angle Maximum (Degrees)	25
Pack Size	1
Sprinkler Location	Above ground,Below ground
Sprinkler Head Type	Gear Drive
Maximum Rotation (Degrees)	360
Material	Polyethylene
Riser	Riser Required
Mounting	In-Ground Install
Sprinkler Head Material	Plastic
Maximum Gallons Per Minute	4.2
Inlet Type	Female
Sprinkler Head Spray Pattern	Adjustable
Sprinkler Type	Rotary
Returnable	180-Day
Thread Type	Female
Head Material	Plastic
Maximum Spray Distance (ft.)	52
Maximum Coverage Area (sq ft.)	8495
Features	Adjustable
Package Quantity	1
Product Height (in.)	10.25 in
Product Width (in.)	2 in
Retracted Height (in.)	0
Product Depth (in.)	2 in
Product Diameter (in.)	0.50 in
Manufacturer Warranty	6 year
