Rain Bird Anti-Siphon Valve 1 in. 150 psi
Regular price $36.99/
Shipping calculated at checkout.
This professional grade anti-siphon valve replaces Rain Bird and other irrigation valves installed above ground with 1 in. female threaded inlet and outlet. It can be used with any 24 volt AC irrigation timer. Its unique reverse-flow design helps prevent flooding in the event of internal diaphragm failure, keeping the valve closed and saving water. Anti-Siphon valves should always be installed at least 6 inches above the highest head on the valve line, and should never have another valve installed further down the line from the main valve. After installation and before startup, always the flush system of dirt and debris manually using the valve's external bleed screw. Equipped with the additional advantage of adjustable flow control, this model helps prevent wasteful misting when water pressure is too high. A top mounted, easy turn flow control knob allows you to optimize flow to the zone, permitting sprinklers to water at their most efficient rate for more uniform coverage. This valve can be applied with all types of watering devices including Rain Bird spray heads (1800, 600), and rotors (22SA, 32SA, 42SA+, 52SA, LG3 and AG5) as well as Drip zones when properly installed together with a pressure regulator and filter.
- Anti-Siphon (above ground) mounting
- Heavy duty construction with stainless steel screws
- Flow control allows adjusting flow to the zone, optimizing sprinkler performance
- Energy efficient, low power encapsulated solenoid with captured plunger for long lasting dependability
- Buna-N diaphragm offers superior performance in harsh water environments
- External bleed to manually flush system of dirt and debris prior to installation and system start-up
- Spray-free internal bleed for manual operation
Features
| Assembly Code | N |
| Country Of Origin | MX |
| Delivery Offered | Y |
| Department Number | 7 |
| Display Only Item | N |
| Dollar Velocity Code | C |
| Feature 10 Text | |
| Feature 1 Text | Anti-Siphon (above ground) mounting |
| Feature 2 Text | Heavy duty construction with stainless steel screw |
| Feature 3 Text | Flow control allows adjusting flow to the zone, op |
| Feature 4 Text | Energy efficient, low power encapsulated solenoid |
| Feature 5 Text | Buna-N diaphragm offers superior performance in ha |
| Feature 6 Text | External bleed to manually flush system of dirt an |
| Feature 7 Text | Spray-free internal bleed for manual operation |
| Feature 8 Text | |
| Feature 9 Text | |
| Item Restriction Flag | N |
| Product Source Code | B |
| Product Type | Anti-Siphon Valve |
| Product Type Code | 009010101019 |
| Sub-category | Underground Sprinkler Valves |
| Proposition 65 Flag | N |
| Retail Velocity Code | C |
| Shipping Code | Y |
| Store Availability Rank | 07 |
| Unit Velocity Code | D |
| Vendor Name | RAIN BIRD CORPORATION-CONSUMER |
| Vendor Number | 77188 |
| Web Order Multiple | 1 |
| Proposition 65 Warning | |
| ISPU Only Item Flag | N |
| Category | Watering and Irrigation |
| Merchandise Class Description | UNDER GROUND IRRIGATION |
| Product Group Description | VALVES |
| Product Type Noun | Valve |
| Search Field | Rain Bird Anti-Siphon Valve 1 in. 150 psi Watering |
| Sales Rank | 033 |
| What's Included | |
| DIFM Service Code | N |
| Warranty Code | N |
| Old Default Base SKU | |
| Paint Code | N |
| Default Base SKU | |
| Accessory SKUs | |
| Replacement Part SKUs | |
| Brand Name | Rain Bird |
| Local SKU Available Stores | ALL |
| Local SKU Store SKUs | 7517824 |
| Adjustable Flow Control | yes |
| Inlet Size | 1-inch |
| Material | plastic |
| Maximum Pressure | 150-pound-per-square-inch |
| Voltage | 24-volt |
